Thread type : M/PG/NPT/G
Material: SS304/SS316L
Claw: PA66 (Nylon), UL94-V2
Hermetic seal: EPDM、Silicone rubber
O-Ring: EPDM、Silicone rubber
Protection degree: IP68-10 bar
Temperature: Static state: -40℃ to 100℃, Short time to 120
Dynamic state: -20℃ to 80℃, Short time to 100℃
This stainless steel cable gland is designed to securely anchor and seal the end of an electrical cable entering an enclosure or piece of equipment. It provides robust mechanical strain relief, excellent corrosion resistance, and reliable ingress protection in harsh industrial, marine or offshore environments.
Materials:
Performance:
Protection:
Applications:
Key Benefits
High strength & corrosion resistance
IP68 waterproof & dustproof
Heat & cold resistant
Easy to install, maintenance-free
Global certification: CE, UL, RoHS
 |
||||||
| PRODUCT PARAMETER | ||||||
| Welcome to Our Website. We Are Happy to Serve You | ||||||
| Fitting Material: | Stainless Steel 304/316L | |||||
| Material For Clamping Jaws: | PA66(Nylon),UL94-V2 | |||||
| Material For Sealing Components: | EPDM、Silicone rubber | |||||
| O-ring Material: | EPDM、Silicone rubber | |||||
| Protection Degree: | IP68-10 bar | |||||
| Temperature: | Static state:-40 to 100℃, Short time to 120℃ Dynamic state:-20℃ to 80℃,Short time to 100℃ |
|||||
| Specifications: | unit: mm | |||||
| Item | Range Φ mm |
Tread Length GL mm |
Thread O.D. AG mm |
Joint Length H mm |
Spanner size mm |
Code |
| M8×1 | 2-5 | 6 | 8 | 14 | 12 | HX-SS.M8 |
| M10×1 | 2-5 | 7 | 10 | 17 | 14 | HX-SS.M10-5 |
| M10×1 | 3-6.5 | 7 | 10 | 17 | 14 | HX-SS.M10 |
| M12×1.5 | 3-6.5 | 7 | 12 | 17 | 14/15 | HX-SS.M12 |
| M12×1.5 | 4-8 | 8 | 12 | 17 | 18/15 | HX-SS.M12-8 |
| M14×1.5 | 4-8 | 8 | 14 | 19 | 18 | HX-SS.M14 |
| M16×1.5 | 4-8 | 8 | 16 | 19 | 18 | HX-SS.M16 |
| M16×1.5 | 5-10 | 8 | 16 | 19 | 20/18 | HX-SS.M16-10 |
| M18×1.5 | 5-10 | 8 | 18 | 19 | 20 | HX-SS.M18 |
| M20×1.5 | 6-12 | 8 | 20 | 20 | 22 | HX-SS.M20 |
| M20×1.5 | 10-14 | 8 | 20 | 20 | 24/22 | HX-SS.M20-14 |
| M22×1.5 | 10-14 | 8 | 22 | 20 | 24 | HX-SS.M22 |
| M25×1.5 | 10-14 | 9 | 25 | 22 | 24/27 | HX-SS.M25-14 |
| M25×1.5 | 12-16 | 9 | 25 | 22 | 27 | HX-SS.M25-16 |
| M25×1.5 | 13-18 | 9 | 25 | 22 | 30 | HX-SS.M25-18 |
| M27×1.5 | 13-18 | 9 | 27 | 22 | 30 | HX-SS.M27 |
| M32×1.5 | 15-22 | 10 | 32 | 25 | 35 | HX-SS.M32 |
| M32×1.5 | 18-25 | 10 | 32 | 28 | 40/35 | HX-SS.M32-25 |
| M33×1.5 | 15-22 | 10 | 33 | 29 | 35/36 | HX-SS.M33 |
| M36×1.5 | 18-25 | 10 | 36 | 28 | 40 | HX-SS.M36 |
| M40×1.5 | 18-25 | 10 | 40 | 28 | 40/45 | HX-SS.M40-25 |
| 22-30 | 10 | 40 | 30 | 45 | HX-SS.M40-30 | |
| 25-33 | 10 | 40 | 30 | 50/45 | HX-SS.M40-33 | |
| M42×1.5 | 22-30 | 10 | 42 | 30 | 45 | HX-SS.M42 |
| M47×1.5 | 25-33 | 11 | 47 | 30 | 50 | HX-SS.M47 |
| M48×1.5 | 25-33 | 11 | 48 | 30 | 50 | HX-SS.M48 |
| M50×1.5 | 32-38 | 12 | 50 | 31 | 55/56 | HX-SS.M50 |
| M54×1.5 | 32-38 | 12 | 54 | 31 | 55/57 | HX-SS.M54 |
| M60×1.5 | 37-44 | 13 | 60 | 33 | 66/65 | HX-SS.M60 |
| M63×1.5 | 37-44 | 13 | 63 | 33 | 65/68 | HX-SS.M63 |
| M64×2 | 37-44 | 13 | 64 | 33 | 65/68 | HX-SS.M64 |
| M72×2 | 42-52 | 15 | 72 | 35 | 75 | HX-SS.M72 |
| M75×2 | 42-52 | 15 | 75 | 35 | 75/80 | HX-SS.M75 |
| M80×2 | 55-62 | 15 | 80 | 37 | 85 | HX-SS.M80 |
| M88×2 | 65-70 | 18 | 88 | 38 | 94 | HX-SS.M88 |
| M90×2 | 65-70 | 18 | 90 | 38 | 94/96 | HX-SS.M90 |
| M100×2 | 75-85 | 20 | 100 | 53 | 110 | HX-SS.M100 |
|
||||||
| PRODUCT PARAMETER | ||||||
| Welcome to Our Website. We Are Happy to Serve You | ||||||
| Fitting Material: | Stainless Steel 304/316L | |||||
| Material For Clamping Jaws: | PA66(Nylon),UL94-V2 | |||||
| Material For Sealing Components: | EPDM、Silicone rubber | |||||
| O-ring Material: | EPDM、Silicone rubber | |||||
| Protection Degree: | IP68-10 bar | |||||
| Temperature: | Static state:-40 to 100℃, Short time to 120℃ Dynamic state:-20℃ to 80℃,Short time to 100℃ |
|||||
| Specifications: | unit: mm | |||||
| Item | Range Φ mm |
Tread Length GL mm |
Thread O.D. AG mm |
Joint Length H mm |
Spanner size mm |
Code |
| PG7 | 3-6.5 | 7 | 12.5 | 19.0 | 15 | HX-SS.PG7 |
| PG9 | 4-8 | 8 | 15.2 | 20.0 | 18 | HX-SS.PG9 |
| PG11 | 5-10 | 8 | 18.6 | 21.0 | 20 | HX-SS.PG11 |
| PG13.5 | 6-12 | 8 | 20.4 | 22.0 | 22 | HX-SS.PG13.5 |
| PG16 | 10-14 | 8 | 22.5 | 23.0 | 24 | HX-SS.PG16 |
| PG19 | 10-14 | 9 | 25.0 | 23.0 | 27 | HX-SS.PG19 |
| PG21 | 13-18 | 9 | 28.3 | 27.0 | 30 | HX-SS.PG21 |
| PG25 | 15-22 | 10 | 32.0 | 29.0 | 35 | HX-SS.PG25 |
| PG29 | 18-25 | 10 | 37.0 | 31.0 | 40 | HX-SS.PG29 |
| PG36 | 25-33 | 11 | 47.0 | 37.0 | 50 | HX-SS.PG36 |
| PG42 | 32-38 | 12 | 54.0 | 38.0 | 55/57 | HX-SS.PG42 |
| PG48 | 37-44 | 13 | 59.3 | 38.0 | 65/66 | HX-SS.PG48 |
| PG63 | 42-52 | 15 | 72.0 | 42.0 | 75 | HX-SS.PG63 |
|
||||||
| PRODUCT PARAMETER | ||||||
| Welcome to Our Website. We Are Happy to Serve You | ||||||
| Fitting Material: | Stainless Steel 304/316L | |||||
| Material For Clamping Jaws: | PA66(Nylon),UL94-V2 | |||||
| Material For Sealing Components: | EPDM、Silicone rubber | |||||
| O-ring Material: | EPDM、Silicone rubber | |||||
| Protection Degree: | IP68-10 bar | |||||
| Temperature: | Static state:-40 to 100℃, Short time to 120℃ Dynamic state:-20℃ to 80℃,Short time to 100℃ |
|||||
| Specifications: | unit: mm | |||||
| Item | Range Φ mm |
Tread Length GL mm |
Thread O.D. AG mm |
Joint Length H mm |
Spanner size mm |
Code |
| G1/4 | 3-6.5 | 7 | 19 | 13.1 | 14/16 | HX-SS.G1/4 |
| G3/8 | 4-8 | 8 | 21 | 16.6 | 18/20 | HX-SS.G³/8 |
| G1/2 | 6-12 | 8 | 22 | 20.9 | 22/24 | HX-SS.G1/2 |
| G3/4 | 13-18 | 9 | 25 | 26.4 | 30 | HX-SS.G3/4 |
| G1 | 18-25 | 10 | 29 | 32.2 | 40 | HX-SS.G1 |
| G1-1/4 | 25-33 | 11 | 35 | 41.9 | 50 | HX-SS.G1-1/4 |
| G1-1/2 | 32-38 | 12 | 37 | 47.8 | 55/56 | HX-SS.G1-1/2 |
| G2 | 37-44 | 14 | 38 | 59.6 | 65 | HX-SS.G2 |
| G2-1/2 | 42-52 | 16 | 42 | 75.1 | 75/80 | HX-SS.G2-1/2 |
| G3 | 65-70 | 18 | 45 | 88 | 94 | HX-SS.G3 |
| NPT1/4 | 3-6.5 | 7 | 19 | 13.6 | 14/16 | HX-SS.NPT1/4 |
| NPT3/8 | 48 | 8 | 21 | 17.0 | 18 | HX-SS.NPT3/8 |
| NPT1/2 | 6-12 | 8 | 23.5 | 21.2 | 22 | HX-SS.NPT1/2 |
| NPT3/4 | 13-18 | 9 | 26 | 26.5 | 30 | HX-SS.NPT3/4 |
| NPT1 | 18-25 | 10 | 33 | 33.2 | 40 | HX-SS.NPT1 |
| NPT1-1/4 | 22-32 | 11 | 37.5 | 41.9 | 50 | HX-SS.NPT¹1/4 |
| NPT1-1/2 | 30-38 | 12 | 38.5 | 48.0 | 55 | HX-SS.NPT11/2 |
| NPT2 | 37-44 | 14 | 40 | 60.0 | 65 | HX-SS.NPT2 |
| NPT2-1/2 | 42-52 | 16 | 40 | 72.6 | 75/80 | HX-SS.NPT2-1/2 |
| NPT3 | 65-70 | 18 | 41 | 88.6 | 94 | HXSS.NPT3 |
| Note: NPT models come standard without nuts and are optional | ||||||
It is widely used in mechanical automation, new energy vehicles, wind power energy storage, electronic communications, marine and aviation, nuclear power plants, and various other scenarios
Built with nickel-plated brass and EPDM/silicone rubber seals,this IP68-rated metal waterproof connector guarantees cable durability in harsh conditions like sandstorms, snow, ice, and heavy rain.
It can be dust-proof, salt-proof, acid-alkaline, alcohol-grease and general solvent, suitable for outdoor harsh environments Plug and play, convenient and fast.
