Thread type: M/PG
Material: Nickel-plated brass
Claw: PA(Nylon), UL94-V2
Hermetic seal: NBR, Silicone rubber
O-Ring: NBR, Silicone rubber
Protection degree: IP68-10 bra
Temperature: Static state: -40℃ to 100℃
Dynamic state: -20℃ to 80℃
Large range brass cable gland use High-quality stainless steel material, good waterproof performance, rust-proof, dust-proof and anti-corrosion. We put an end to the use of second-hand materials to ensure the quality and durability of use. This product consists of four parts, nut, nut, main body, and sealing ring.
Instructions
Now put the body into the large range brass cable gland board, then fix it with a nut, then insert the thing you want to waterproof into the tightening claw, and then tighten it with the clamping ring for positive rotation.
Thread Type ：M
| Item | Range | Tread Length | Thread O.D. | Joint Length | Spanner size | Code |
| Φ mm | GL mm | AG mm | H mm | mm | ||
| M12×1.5 | 4-8 | 8 | 12 | 17 | 17/14 | HX-NPM12-8 |
| M14×1.5 | 5-10 | 8 | 14 | 20 | 20/17 | HX-NPM14-10 |
| M16×1.5 | 5-10 | 8 | 16 | 20 | 20/18 | HX-NPM16-10 |
| M18×1.5 | 6-12 | 8 | 18 | 21 | 22/20 | HX-NPM18-12 |
| M20×1.5 | 10-14 | 8 | 20 | 22 | 24/22 | HX-NPM20-12 |
| M22×1.5 | 12-16 | 8 | 22 | 27 | 27/24 | HX-NPM22-16 |
| M24×1.5 | 12-16 | 9 | 24 | 27 | 27 | HX-NPM24-16 |
| M25×1.5 | 13-18 | 9 | 25 | 27 | 30/27 | HX-NPM25-18 |
| M30×2 | 15-22 | 9 | 30 | 27 | 35/32 | HX-NPM30-22 |
| M32×1.5 | 18-25 | 10 | 32 | 31 | 40/35 | HX-NPM32-25 |
| M40×1.5 | 25-33 | 11 | 40 | 37 | 50/45 | HX-NPM40-33 |
| M50×1.5 | 37-44 | 14 | 50 | 38 | 64/55 | HX-NPM50-44 |
| M63×1.5 | 42-52 | 14 | 63 | 38 | 78/68 | HX-NPM63-52 |
| M72×2 | 55-62 | 18 | 72 | 45 | 88/78 | HX-NPM72-62 |
Thread Type ：PG
| Item | Range | Tread Length | Thread O.D. | Joint Length | Spanner size | Code |
| Φ mm | GL mm | AG mm | H mm | mm | ||
| PG7 | 4月8日 | 6.5 | 12.5 | 17 | 14/15 | HX-NPPG7-8 |
| PG9 | 5月10日 | 8 | 15.2 | 19 | 17/18 | HX-NPPG9-10 |
| PG11 | 6月12日 | 8 | 18.6 | 21 | 20/21 | HX-NPPG11-12 |
| PG13.5 | 10月14日 | 8 | 20.4 | 22 | 22/23 | HX-NPPG13.5-14 |
| PG16 | 13-18 | 8 | 22.5 | 23 | 24/25 | HX-NPPG16-18 |
| PG21 | 15-22 | 9 | 28.3 | 27 | 30 | HX-NPPG21-22 |
| PG29 | 22-30 | 10 | 37 | 31 | 40 | HX-NPPG29-30 |
| PG36 | 32-38 | 11 | 47 | 37 | 50 | HX-NPPG36-38 |
| PG42 | 37-44 | 13 | 54 | 37 | 57 | HX-NPPG42-44 |
| PG48 | 42-52 | 14 | 59.3 | 38 | 64 | HX-NPPG48-52 |
