Junction Box
Body material ： ABS
Stopper material ：PVC
Material characteristics：Impact,heat,low temperature and chemical resistance,excellent electrical performance and surface gloss,etc.
Certificates:CE,ROHS
Protection grade:IP65
Products
VIDEO
Dimension Drawing
Technical Parameter
The junction box is designed to protect and connect cables, ensuring safe and stable operation under various environmental conditions. Made from high-quality materials, it features waterproof, dustproof, and corrosion-resistant properties, suitable for residential, industrial, and commercial applications. Its straightforward design allows for easy installation and maintenance, enhancing the safety and reliability of electrical systems.
Product features and advantages
Removable Panel: The removable panel allows for easy reuse.
High-Quality ABS Material: Made from ABS material, the fittings are strong and durable.
Premium Sealing Strip: Equipped with a high-adhesion PVC sealing strip, it resists corrosion damage and provides waterproof protection.
Application
- Residential Wiring
- Industrial Facilities
- Commercial Buildings
- Outdoor Installations
- Renewable Energy Systems
RA/RA Type
| Model Code | Hole QTY | Hole Size | IP | G. Weight | N. Weight | Qty/Carton | Carton Dimension |
| （mm） | （KG） | （KG） | （cm） | ||||
| HXB-RA/B 50×50 | 4 | 25 | 55 | 13.5 | 12.3 | 300 | 46*38*51 |
| HXB-RA/B 80×50 | 4 | 25 | 55 | 14.7 | 13.4 | 240 | 53*35*62 |
| HXB-RA/B 85x85x50 | 7 | 25 | 55 | 17.2 | 16 | 200 | 53*41*53 |
| HXB-RA/B 100x100x70 | 7 | 25 | 65 | 14.9 | 13.5 | 100 | 62*49*35 |
| HXB-RA/B 150x110x70 | 10 | 25 | 65 | 15.1 | 13.8 | 60 | 67*33*46.5 |
| HXB-RA/B 150x150x70 | 8 | 25 | 65 | 16.3 | 15 | 60 | 84.5*34*45 |
| HXB-RA/B 200x100x70 | 8 | 25 | 65 | 16.6 | 15.3 | 60 | 61*46*42 |
| HXB-RA/B 200x155x80 | 10 | 36 | 65 | 14.5 | 13.2 | 40 | 69.5*43.5*42 |
| HXB-RA/B 200x200x80 | 12 | 36 | 65 | 18 | 16.6 | 40 | 90*46*40.5 |
| HXB-RA/B 255x200x80 | 12 | 36 | 65 | 21.9 | 20.1 | 40 | 55*45*78.5 |
| HXB-RA/B 255x200x120 | 12 | 36 | 65 | 21.9 | 20.1 | 30 | 64*55*62 |
| HXB-RA/B 300x250x120 | 12 | 36 | 65 | 20.3 | 18.4 | 20 | 61.5*55.5*63 |
| HXB-RA/B 400x320x120 | 16 | 36 | 65 | 15 | 13.3 | 10 | 74.5*42.5*61.5 |
KT Type
| Model Code | G. Weight | Qty/Carton | Carton Dimension | Model Code | G. Weight | Qty/Carton | Carton Dimension | |
| （KG） | （cm） | （KG） | （cm） | |||||
| HXB-KT 65×50×55 | 21.5/20.0 | 300 | 52×41×29.5 | HX-KT 200×150×130 | 21.6/20.1 | 40 | 61.5×41×68.5 | |
| HXB-KT 96×65×55 | 25.1/23.6 | 240 | 49.5×40.5×46.5 | HX-KT 200×200×95 | 18.5/17.0 | 30 | 62×42×49.5 | |
| HXB-KT 100×100×75 | 20.4/18.9 | 100 | 52×42×39.5 | HX-KT 200×200×130 | 14.6/13.1 | 20 | 42×42×67 | |
| HXB-KT 110×80×45 | 24.3/22.8 | 200 | 46×42×47 | HX-KT 250×80×70 | 15.7/14.2 | 50 | 52×41×36 | |
| HXB-KT 110×80×70 | 20.0/18.5 | 120 | 57×33.5×45 | HX-KT 250×80×85 | 18.8/17.3 | 50 | 52×42×44.5 | |
| HXB-KT 110×80×85 | 19.7/18.2 | 100 | 57×33.5×45 | HX-KT 250×150×100 | 11.5/10.0 | 20 | 52×32×52 | |
| HXB-KT 125×125×75 | 16.6/15.1 | 60 | 52×39.5×39.5 | HX-KT 250×150×130 | 17.1/15.6 | 30 | 52×47×67 | |
| HXB-KT 125×125×100 | 19.4/17.9 | 60 | 52×39.5×52 | HX-KT 280×190×130 | 10.6/9.1 | 10 | 40×30×67 | |
| HXB-KT 130×80×70 | 21.4/19.9 | 120 | 54×41.5×45 | HX-KT 280×190×180 | 14.5/13.0 | 12 | 58×40×56 | |
| HXB-KT 130×80×85 | 25.4/23.9 | 120 | 54×50×44.5 | HX-KT 280×280×130 | 8.6/7.1 | 6 | 58×58×41 | |
| HXB-KT 160×80×55 | 100 | 42×34×57 | HX-KT 280×280×180 | 9.6/8.1 | 6 | 58×58×56 | ||
| HXB-KT 160×80×95 | 50 | 42×34×49.5 | HX-KT 340×280×130 | 9.5/8.1 | 6 | 57.5×35×41 | ||
| HXB-KT 170×140×95 | 17.8/16.3 | 50 | 57.5×52×49.5 | HX-KT 340×280×180 | 7.9/6.4 | 4 | 57.5×35×37.5 | |
| HXB-KT 175×125×75 | 17.0/15.5 | 50 | 54×52.5×32 | HX-KT 340×190×130 | 10.9/9.4 | 8 | 40×40×54 | |
| HXB-KT 175×125×100 | 11.9/10.4 | 30 | 39.5×37×52 | HX-KT 380×190×180 | 12.5/11 | 6 | 40×59×38 | |
| HXB-KT 175×175×100 | 14.4/12.9 | 30 | 54.5×37×53.5 | HX-KT 380×280×130 | 9.8/8.3 | 6 | 57.5×39×41 | |
| HXB-KT 180×80×70 | 20.4/18.9 | 90 | 56×41×46 | HX-KT 380×280×180 | 8.0/6.5 | 4 | 57.5×39×37.5 | |
| HXB-KT 200×150×100 | 28.5/27 | 30 | 47×42×67 |
